1310nm 5mW Infrared Laser Dot Laser Module Red Laser Communication Sensor Laser

1310nm 5mW Infrared Laser Dot Laser Module Red Laser Communication Sensor Laser

Specification:

Mode: CW

Wavelength: 1310nm

OutputPower: <5mW

OperatingVoltage: 2.8-3.5V

OperatingCurrent: <100mA

Housing Material: Environmentally Aluminum

Mean time to failure: >8000H

LaserSafety: ClassIlIA

DivergenceAngle: <0.7mard

SpotSize: Less than 3mm at 50Millimeter

Lens: Glass Collimating Mirror

Diameterx Length: 12x40mm

Drivercircuit: ACC

OperatingTemperature: -20°~+50°

StorageTemperature: -40°~+85°

Package:

1 x 1310nm 5mW Laser Module
