405nm 300mW 12V Violet-Blue Diodes Adjusted Laser Dot Module w/TTL & Fan Cooling
405nm 300mW 12V Violet-Blue Diodes Adjusted Laser Dot Module w/TTL & Fan Cooling
Couldn't load pickup availability
405nm 300mW 12V Violet-Blue Diodes Adjusted Laser Dot Module w/TTL & Fan Cooling
Description:
Wavelength: 405 nm
Output power: 300mW
Cooling Method: Fan Cooling
Modulation frequency: TTL modulation
Operation Method: continuous work
Finish Color: Blue
Case Material: Aluminum
The circuits control: constant current
Reverse polarity protection: with automatically identify the positive and negative
Operating voltage: DC = 12V
Output Current: I <380mA
Focusable:Yes
Warm-up time: None
Operating Temperature: -10 ℃ ~ +40 ℃
Storage temperature: -10 ℃ ~ +40 ℃
Laser head size: 74mmx30mmx30mm (including fans)
Circuit Board size: 71.5mmx35.5mmx16mm
Details:
The input voltage for this laser is 12V, working voltage >12v can cause damage to the circuit and laser instantly, if you have any technical problems, please contact us!Please protect your eyes before 405nm Blue ray!
This laser module brings TTL modulation, can work long time, is really industry laser module!
Package:
1 x Violet-Blue Diodes Adjusted 405nm 300mW 12V Laser Dot Module w/TTL & Fan Cooling
