Lilly Electronics
780nm-785nm 10mW IR Infrared Diode Laser Dot Module Adjusted 3V-5V 12x35mm New
780nm-785nm 10mW IR Infrared Diode Laser Dot Module Adjusted 3V-5V 12x35mm New
Regular price
$9.00
Regular price
$10.00
Sale price
$9.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
New 780nm-785nm 10mW IR Infrared Diode Laser Dot Module Adjusted 3V-5V 12x35mm
Description:
1.Size:12x35mm (sometime it is 12x40mm due to factory bulk production batch)
2.output power: 10mw
3.Wavelength: 780nm
4.Operation Voltage: DC=3-5VDC
6.Duty cycle: 10 minutes on, 15 seconds off
7.Lens: Plastic
8.Laser shape: Dot
9.Focusable: Yes
Details:
1.The modules are tested and the output power are measured by laser power meter before sending out.
2.The LD in this laser module is 780nm 10mw LASER DIODE original and new. but laser module output power may be less than 10mw, because the output power of the laser module has power loss on the collimating lens, and when you measure the output power, please focus to the smallest point to meaure its real output.
3.It is near IR laser,the laser light cannot be seen by human bare eyes, using DDC/infrared camera can get it. Buyers who buy IR lasers please make sure you know it. since it is IR near red, there is a red bomb. and it is normal. red bomb means a weak red if the ir laser is near red--close to the <700nm wavelength.
4.If you need an absolutely ir laser without red bomb, please add a filter on it.
5.If you need a red laser, please choose a 650nm 660nm one.
Package:
1x Adjusted 780nm-785nm 10mW IR Infrared Diode Laser Dot Module 12x35mm 3V-5V
