USB-CAN Multifunctional CAN USB Adapter 5K-1M Baud Rate 12M/S CAN2.0A/B Support Decoding Compatible ZLG

USB-CAN Multifunctional CAN USB Adapter 5K-1M Baud Rate 12M/S CAN2.0A/B Support Decoding Compatible ZLG

$45.00
$55.00 $45.00
Sale Sold out
Shipping calculated at checkout.
Options
USB-CAN Multifunctional CAN USB Adapter 5K-1M Baud Rate 12M/S CAN2.0A/B Support Decoding Compatible ZLG
Introduction:
The USBCAN1 adapter basic version is an integrated 1-channel CAN2.0 USB to CAN adapter that uses a USB2.0 interface and is compatible with the USB1.1 bus. PCs can connect to CAN bus networks through the USB bus. Compliant with CAN2.0A/B specifications, supporting baud rates of 5Kbps~1Mbps, supporting canopen, secondary development Socketcan， Can be applied to Windows and Linux systems, supporting CanAst software

Specifications:
Name: UTC2201 Adapter
Material: Flame retardant ABS
Color: White
CAN interface: screw crimping terminal (CANH+GND+CANL)
Electrical properties: Isolation: DC3000 PC interface: USB 1.1/2.0/3.0, Power supply: USB Operating temperature: -40-85 ° C
Matching resistor: Built in 120 ohms (switchable)
Operating systems: Windows (x86/64)/Linux (x86/64/ARM)/Zhongbiao Kirin (Loongson), etc
Supported software: Can utls
1. Six Leaf Tree Original CanAssistant
2. Zhou Ligong canTest/canPro/zcanPro
3. Same star TSMaster
Size: 7x4.5x2.5cm
USB speed: 2.0 full speed 12M/S
Transmission and reception capacity: 8500 frames per second 1M
CAN baud rate: 5K-1M
CAN quantity: 1 (high-speed)+isolation (optional)
CAN standard: Supports both CAN2.0A and CAN2.0B protocols, compliant with ISO
Secondary development: support (original code use cases), C/C++/C #/QT/PYTHON, etc
Driver: No driver installation required
ZLG is compatible with Zhou Ligong drivers and software, including the latest ZCANPRO


Package：
1x USB-CAN Multifunctional USB Adapter 5K-1M Baud Rate 12M/S CAN2.Support Decoding
